35hp 1000cc ZONSEN E-Start 8 inch Gas Powered Commerical Wood Chipper with Intelligent Hydraulic Feeding System , CROBA TX1000

Engine Parameter
Engine Brand Model
Zonsen GB1000EI
Engine Power
35HP
Torque
74Nm
Fuel Tank Capacity
18L
Max Fuel Consumption
2.38gal/h
Fuel Type
Gasoline 92#
Air Cleaner
Double Filtration
Oil Filter
Screw Mountiing
Recommended Oil
SAE 10W-30
Oil Volume with Filter
2.5L
Maximum Continuous Working Angle
20°
Cooling Medium
Forced Cooling
Alternator
25A/300W
Clutch Type
Manual Clutch
Engine Shaft Diameter
1.125 in
Tensioner
Spring Automatic Tensioning
Belt
2SB1505LE
General Dimensions And Weight
Overall Length-Feed Table Up
135 in
Overall Length-Feed Table Down
155 in
Overall Width
55 in
Overall Height-Discharge Chute Up
79 in
Overall Height-Discharge Chute Down
92 in
Overall Weight
1874 lbs
Tongue Weight
198 lbs
Feed System
Feed Roller Orientation
Horizontal
Feed Roller Nos.
1
Feed Roller Clamp Load
344 lbs
Knife Nos.
4
Number Of Feed Roller Motors
1
Feed Roller Clamping Mechanism Type
Spring + Feeding Roller Weight
Feed Roller Dimension
φ12*11 in
Minimum Distance From Feed Roller To Blade Housing
5 in
Weight Of Feed Roller Assembly
123 lbs
Feed Speed
54ft/min
Infeed Table Height
22 in
Infeed Table Length
24 in
Infeed Table Width
41 in
Infeed Throat Size
12*8 in
Distance From Feed Roller To End Of Feed Table
61 in
Distance From Feed Table To Ground
30 in
Safety System
Bottom Feed Stop Bar Function
Feed Roller Stopped – Reset
Bottom Feed Stop Bar
Standard
Bottom Feed Stop Bar Diameter
1.2 in
Bottom Feed Stop Bar Material Thickness
0.07 in
Stop Bar Resetting Method
Manual Reset
Three-Position Feed Control Bar
Standard
Control Bar Diameter
1 in
Control Bar Material Thickness
0.07 in
Control Bar Position Function
Forward/Stop/Reverse
Red Emergency Stop Button
Stop The Engine
Red Emergency Stop Button Reset Method
Manual Reset
Blade Housing Parameter
Chipping Capacity
8 in
Blade Housing Width
7 in
Cutting Disc Size
30*0.7 in
Cutting Disc Rotating Speed
1800
Weight With Shaft
225 lbs
Safety Lock – Number Of Positions
1
Blade Size
4*1*0.5 in
Blade Cutting Edge Nos.
2
Blade Bolt Nos.
3
Vertical Anvil Size
3.5*7.8*0.5 in
Vertical Anvil Cutting Edge Nos.
2
Horizontal Anvil Size
3.7*11.6*0.4 in
Horizontal Anvil Cutting Edge Nos.
2
Blade Material
A8 Steel
Anvil Material
Cr12
Blade Holder Replaceable
No
Fan Blades Nos.
4
Fan Blade Fixation Method
Bolt Fixing
Fan Blade Air Flow
3249CFM
Disc
Bearing Nos.
2
Bearing Hole Diameter
2 in
Bearing Type
Spherical Bearing
Bearing Brand
SKF
Dynamic Capacity
23.2KN
Static Capacity
27KN
Tensioner
Automatic Tensioning
Belt Type
Combined Belt
Discharge System
Chute Height
97 in
Flange Thickness
0.2 in
Side Wall Thickness
0.07 in
Chute Rotation Angle
360°
Rotation Type
Manual
Rotatation Lock
Included
Rotational Lock Type
Tighten The Dual Handle Bolts
Hydraulic System
Tank Capacity
7.4 gal
Recommended Oil Type
hm46
System Type
Open Center
Filtration Method
Return Oil Filtration – 10um
Pump flow at the maximum RPM
4.2 gal
Maximum Pressure
2102psi
Electric Control Parameter
System Voltage
12V
Battery
12V 48AH
Display Screen Size
4.3 in.
Controller Function
Timer, Automatic Control, Status Display, Speed Display, Etc.
Shutdown System
Engine
Trailer Lights
Vehicle Power Supply
Others
Tow Ball Size
2″ Coupler Hitch / 2″ Ball Coupler
Hook Type
Ball Coupler
Axle Load-Bearing Capacity
2756 lbs Torsion Shaft
Mud Guard
Bolt Fixing
Torque Shaft Type
Solid Torque Shaft
Tyre
φ594x165R13
