100 Ton H-Frame Air/Hydraulic Shop Press with Hand Winch, Fully Welded Steel Frame, Safety Guard, Foot Pedal Control, HSP100

100 Ton H-Frame Air/Hydraulic Shop Press with Hand Winch, Fully Welded Steel Frame, Safety Guard, Foot Pedal Control, HSP100

Shop Press

£3,638.41

Indicative price — contact our team to confirm and quote

  • No obligation
  • Fast response
  • Expert advice
Quantity
UK BasedExpert AdviceFree QuoteTechnical Support
Share: Email

Rated Capacity
100 Tons
Number of Bed Adjustment Holes
7
Operation Type
Air & Manual Dual Operation
Bed Adjustment Hole Spacing
5.9 in
Air Pressure
110-125 PSI
Frame Construction
Fully Welded Heavy-Duty H-Frame
Ram Stroke
11.8 in
Assembled Size (H x D x W)
75.6 x 29.6 x 40.6 in
Ram Diameter
3.4 in
Internal Frame Width
30.9 in
Cylinder Bore
5.5 in
Protective Grid Guard Size
27 x 24 in
Ram Range of Movement
4.5 in Left / Right from Center
Recommended Hydraulic Oil
AW32 Hydraulic Oil
Bed Depth
8 in
Gauge Type
4 in Oil-Filled Pressure Gauge
Bed Height
11.8 in
Included Accessories
Protective Grid Guard, Hand Winch, Foot Pedal Valve, V-Blocks
Minimum Ram to Bed
3.5 in
Packing Size (LxWxH)
81.1 x 44.5 x 17.3 in
Maximum Ram to Bed
33.1 in
Weight (N.W/G.W.)
1223.6 lbs / 1333.8 lbs
Ram Retraction
Twin Springs

Specifications are provided for comparison only and may be based on engineering calculations rather than physical measurements. They are subject to change without notice and vary with design, manufacturing and operating conditions. Confirm exact specifications with us before ordering.
